# Embulk Bulk Import From Tsv Files

You can import data from TSV files into Treasure Data using *Embulk*, an open-source bulk data loader.

![](/assets/image-20191021-194448.33463c75cf3cb8b1a37595872537be60b30cee4f234d918acbc8fa2cb005f933.d2564ff8.png)

## Prerequisites

- Basic knowledge of Treasure Data.
- Basic Knowledge of [Embulk](http://www.embulk.org/docs/).
- [JRuby](https://www.jruby.org/download) needs to be installed and configured. Embulk v0.10.50 and v0.11.0 do not include JRuby, so you will need to manually install and configure it. (For details on configuring embulk with JRuby see the  "JRuby" section of [Embulk v0.11 is coming soon](https://www.embulk.org/articles/2023/04/13/embulk-v0.11-is-coming-soon.html). )


## What is Embulk?

Embulk enables you to transfer data between various databases, storage locations, file formats, and cloud services.

## How to Install Embulk

### Linux, Mac and BSD

Embulk is a Java application. Make sure that Java is installed.

Following 4 commands install Embulk to your home directory:


```bash
curl --create-dirs -o ~/.embulk/bin/embulk -L "http://dl.embulk.org/embulk-latest.jar"
chmod +x ~/.embulk/bin/embulk
echo 'export PATH="$HOME/.embulk/bin:$PATH"' >> ~/.bashrc
source ~/.bashrc
```

### Windows

Embulk is a Java application. Make sure that Java is installed.

You can download `embulk.bat` using the following command on cmd.exe or PowerShell.exe:


```
PowerShell -Command \
  "& {Invoke-WebRequest http://dl.embulk.org/embulk-latest.jar -OutFile embulk.bat}"
```

## How to install Treasure Data Plugin

You can use plugins to load data from and to various systems and file formats. Select to view a list of publicly released plugins: [list of plugins by category](https://plugins.embulk.org/).

The following command installs embulk-output-td plugin, which imports records to Treasure Data.


```bash
embulk gem install embulk-output-td
```

# Create a Seed Configuration File

Using your favorite text editor, create embulk config file (for eg:seed.yml) defining input(file) and ouput(TD) parameters. Example:


```yaml
in:
    type: file
    path_prefix: /path/to/files/sample_    # path of *.csv or *.tsv file on your local machine
out:
    type: td
    apikey: xxxxxxxxxxxx
    endpoint: api.treasuredata.com
    database: dbname
    table: tblname
    time_column: time
    mode: replace
    #by default mode: append is used, if not defined. Imported records are appended to the target table with this mode.
    #mode: replace, replaces existing target table
    default_timestamp_format: '%Y-%m-%d %H:%M:%S'
```

This is Sample Data.


```
id,account,time,purchase,comment
1,32864,2015-01-27 19:23:49,20150127,embulk
2,14824,2015-01-27 19:01:23,20150127,embulk jruby
3,27559,2015-01-28 02:20:02,20150128,"Embulk ""TSV"" parser plugin"
4,11270,2015-01-29 11:54:36,20150129,NULL
```

For further details about additional parameters available for embulk-local-file-input, refer to [Embulk Local file input](http://www.embulk.org/docs/built-in.html#local-file-input-plugin) Also details about embulk-output-td, refer to the [TD output plugin for Embulk](https://github.com/treasure-data/embulk-output-td#td-output-plugin-for-embulk).

## Guess Fields (Generate load.yml)

Embulk guess option uses `seed.yml` to read the target file and automatically guesses the column types and settings, and creates a new file `load.yml` with this information.


```bash
embulk guess seed.yml -o load.yml
```


```yaml
in:
  type: file
  path_prefix: /path/to/files/sample_
  'last_path:': /path/to/files/sample_02.tsv
  parser:
    charset: UTF-8
    newline: CRLF
    type: tsv
    delimiter: ','
    quote: '"'
    escape: '"'
    null_string: 'NULL'
    trim_if_not_quoted: false
    skip_header_lines: 1
    allow_extra_columns: false
    allow_optional_columns: false
    columns:
      - name: id
        type: long
      - name: account
        type: long
      - name: time
        type: timestamp
        format: '%Y-%m-%d %H:%M:%S'
      - name: purchase
        type: timestamp
        format: '%Y%m%d'
      - name: comment
        type: string
  out:
    type: td
    apikey: xxxxx
    endpoint: api.treasuredata.com
    database: dbname
    table: tblname
    time_column: time
    mode: replace
    default_timestamp_format: '%Y-%m-%d %H:%M:%S'
```

Add the "auto_create_table: true" parameter to the load.yml, so that tables that do not exist are automatically.

This is a sample of the auto_create_table parameter in a .yml file.


```yaml
out:
  type: td
  apikey: your apikey
  endpoint: api.treasuredata.com
  database: dbname
  table: tblname
  time_column: created_at
  auto_create_table: true
  mode: append
```

You must create the database and table in TD, prior to executing the load job. Alternative: If you either: 1) must add a database or 2) do not add the auto_create_table parameter in a .yml file and must add a table, run the following TD commands:


```bash
td database:create dbname
td table:create dbname tblname
```

You can also create the database and table using [TD Console](https://console.treasuredata.com/app/databases).

Now, you may preview the data using `embulk preview load.yml` command. If any of the column types or data seems incorrect you can edit `load.yml` file directly and preview again to verify. If the `guess` option doesn’t yield satisfactory results, you can change parameters in `load.yml` according to your requirements manually by using [CSV/TSV parser plugin options](http://www.embulk.org/docs/built-in.html#csv-parser-plugin).


```
embulk preview load.yml
```

## Execute Load Job

Finally, issue the import job by running the following command:


```
embulk run load.yml
```

It may take a few minutes to hours for the job to complete, depending on the size of the data.

## Appendix

You can also import data from TSV files using the Bulk Import program (td-import). However, be advised that the td-import is not actively maintained and is a candidate for deprecation in the future. Therefore, we strongly recommend using Embulk.
